34.5V 5kW Xenon Short Arc Lamp 220000lm Stage Lighting

Brand Name:	UVIR
Model Number:	XUV5000/ STAGE
MOQ:	10
Price:	Negotiable
Payment Terms:	L/C,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Keyword:

Xenon Short Arc Lamp

Lifetime:

800h

Application:

Stage Lighting

Voltage:

34.5V

Luninous Flux:

220000lm

Overal Length(1):

420mm

Operating Length(2):

390mm

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box.

Highlight:

6kw High Pressure Xenon Arc Lamp

34.5V High Pressure Xenon Arc Lamp

high pressure arc lamps 220000lm

Product Description

34.5V 5kw High Pressure Xenon Arc Lamp 220000lm For Stage Lighting

Product Specifications

Attribute	Value
Keyword	Xenon Short Arc Lamp
Lifetime	800h
Application	Stage lighting
Voltage	34.5V
Luminous Flux	220000lm
Overall Length (1)	420mm
Operating Length (2)	390mm

Product Overview

XUV5000/STAGE 34.5V 5kw Temperature Short Type-Xenon Arc Lamp

We specialize in manufacturing and wholesale distribution of ultraviolet lamps, infrared lamps, ultraviolet germicidal lamps, xenon lamps, and related accessories including lamp stands and transformers. Custom solutions available to meet specific requirements.

High pressure short arc xenon lamp operates at pressures above 10 atmospheres
Compact design with arc length of several millimeters and spherical shell configuration
High brightness point light source with 6000K color temperature closely matching sunlight
Excellent color rendering makes it ideal for film projection, searchlights, train headlights, and solar simulation

Technical Parameters

Parameter	Value
Lamp Model	XUV5000/STAGE
Operating Current	145A
Operating Voltage	34.5V
Electrode Distance	13mm
Height of Light Center	175mm
Diameter	70mm
Luminous Flux	220000lm
Overall Length (1)	420mm
Operating Length (2)	390mm
Life Time	800h

Available Models

Type	Current (A)	Voltage (V)	Flux (lm)	Cooling Speed	Electrode Distance	Diameter (mm)	Length 1 (mm)	Length 2 (mm)	Light Center (mm)
XUV1000/STAGE	45	22	32000	5	4.7	40	285	245	125
XUV2000/STAGE	70	28	75000	6	5.5	52	360	320	145
XUV3000/STAGE	100	30	130000	13	6	55	395	365	170
XUV4000/STAGE	130	31	155000	13	6.5	60	410	380	170
XUV5000/STAGE	145	34.5	220000	13	7.5	70	420	390	175
XUV6000/STAGE	155	38	250000	15	8.5	75	420	390	175
XUV7000/STAGE	160	43	310000	15	9.3	75	425	395	175
XUV10000/STAGE	195	50	480000	15	10.5	90	444	414	175
