High-Pressure Mercury UV Curing Lamp with 417nm Wave Peak and 2-10KW Power for Industrial Curing Applications

High-Pressure Mercury UV Curing Lamp with 417nm Wave Peak and 2-10KW Power for Industrial Curing Applications

Brand Name:	UVIR
Model Number:	XUV 014030 ACG FS
MOQ:	10
Price:	Negotiable
Payment Terms:	L/C,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Type:

Mercury Lamp

Wave Peak:

417nm

Product Name:

Mercury Uv Curing Lamp

Voltage:

380-1530V

Power:

2-10kw

Application:

Electronic Components ,Printing，Furniture,Decorative Materials And Other Industries Curing

Total Length:

175-1425mm

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box.

Highlight:

417nm Wave Peak UV Curing Lamp

2-10KW Power High-Pressure Mercury Lamp

Industrial Curing Applications UV Mercury Lamp

Product Description

UV High-Pressure Mercury Lamp for Industrial Curing

Product Overview

High-performance UV exposure lamp designed for industrial curing applications with wavelength of 417nm and power range of 2-10KW.

Key Specifications

Parameter	Specification
Type	Mercury Lamp
Wave Peak	417nm
Voltage	380-1530V
Power	2-10KW
Total Length	175-1425mm

Technical Parameters

Power Output	Wavelength	Arc Length	Material	End Caps	Service Life
2-10KW	417nm	110-1270mm	High Quality Quartz Tube	Ceramic / Metal	800 to 1000 hours

Application Areas

UV ink, UV glue, UV painting, and UV coating applications
Paper glazing and printing circuit boards
Decoration and wooden floor manufacturing
Flexible packaging and color printing
Electronics, glass, and furniture industries

UV Curing Benefits

Improved physical properties of inks, coatings, and adhesives
Increased production speed and capacity
Reduced work-in-progress
Minimized setup/cleanup labor
Environmentally friendly - energy efficient with no emissions
Increased production yield with reduced waste

Detailed Model Specifications

Model No.	Watt (W)	Voltage (V)	Current (A)	Total Length (mm)	Arc Length (mm)	Tube φ (mm)	Base	Wave Peak (nm)
XUV 011020 HCG FS	2	380	5.2	175	110	22.5	HC	417
XUV 014010 ACG FS	1	160	6.2	260	140	22.5	AC	417
XUV 024020 ACG FS	2	135	15	360	240	20	AC	417
XUV 014020 ACG FS	2	160	12.5	260	140	22.5	AC	417
XUV 014020 ACG FS	2	260	7.7	260	140	22.5	AC	417
XUV 014030 ACG FS	3	220	14	260	140	25	AC	417
XUV 029035 ACG FS	3.5	220	22	420	290	15	AC	417
XUV 030036 ACG FS	3.6	220	22	420	300	20	AC	417
XUV 021040 BCG FS	4	450	9	280	210	23	BC	417
XUV 016050 ACG FS	5	380	13	285	160	28	AC	417
XUV 023060 BCG FS	6	500	12	350	230	26	BC	417
XUV 127100 BCG FS	10	1570	7	1425	1270	23	BC	417

If these parameters don't meet your requirements, please contact us. Our professional team can provide technical expertise and custom drawings.

After Sales Service

Package tracking
Technical support
24-hour response time
Discounts for repeat orders
Replacements for quality issues
Strict confidentiality of customer information

Frequently Asked Questions

Q1: Are you factory or trading company?

A: We are a trading company with our own manufacturing facility.

Q2: Can I have a sample first before bulk order?

A: Yes, we provide free samples for quality testing. Customers only need to cover the freight costs.

Q3: What's your delivery date?

A: Samples typically ship in 5-7 working days, with bulk orders delivered in 15-25 working days.

Q4: What's your shipping method?

A: We offer multiple shipping options: Express (TNT, DHL, FedEx, UPS, EMS), Air freight, and Sea freight.

Q5: What's your MOQ?

A: Our minimum order quantity is 100 pieces, though initial sample orders can be smaller.

Q6: Are the products safe enough?

A: All our products undergo rigorous testing and are certified by internationally recognized regulatory bodies and safety organizations.
