High-Pressure Mercury UV Curing Lamp with 417nm Wave Peak Ceramic Head Base and 110-1270mm Arc Length

High-Pressure Mercury UV Curing Lamp with 417nm Wave Peak Ceramic Head Base and 110-1270mm Arc Length

Brand Name:	UVIR
Model Number:	XUV 01 6050 ACG FS
MOQ:	10
Price:	Negotiable
Payment Terms:	L/C,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Arc Length:

110-1270mm

Type:

Mercury Lamp

Wave Peak:

417nm

Place Of Origin:

Guangdong, China

Head Base:

Ceramic

Voltage:

380-1570V

Application:

Light Curing, UV Printing,UV Drying

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box.

Highlight:

417nm Wave Peak UV Curing Lamp

Ceramic Head Base High-Pressure Mercury Lamp

110-1270mm Arc Length Iodine Gallium Lamp

Product Description

UV Curing Lamp for Printing Machines

Iodine Gallium Lamp Overview

Iodine gallium lamps, also known as plate burning lamps or exposure lamps, are metal halide lamps available in fast and slow starting variants. These lamps produce strong emission lines within the 350nm-450nm wavelength range, with peak output at 417nm. They are widely used in PS plate burning, film processing, resin plate exposure, lithography, and various photochemical applications.

Product Features

Available in multiple specifications with power ranging from 0.5KW to 8KW
Accurate spectral peak values and fast startup capabilities
Certified by relevant regulatory authorities
Short plate burning time with high efficiency
Enhanced plate making and photographic quality protection

Technical Specifications

Power Output	2-10KW
Wavelength	417nm
Arc Length	110-1270mm
Material	High Quality Quartz Tube
End Caps	Ceramic / Metal
Service Life	800 to 1000 hours

Professional Curing Solutions

Our professional team provides customized UVA-UVB-UVC-UVV spectrum solutions. We offer comprehensive technical support and design services for painting, coating, adhesive, ink, paint coating UV curing applications, as well as air purification, water treatment, and UV photochemical reactions.

Available Product Models

Model No.	Watt (W)	Voltage (V)	Current (A)	Total Length (mm)	Arc Length (mm)	Tube φ (mm)	Base	Wave Peak (nm)
XUV 011020 HCG FS	2	380	5.2	175	110	22.5	HC	417
XUV 014010 ACG FS	1	160	6.2	260	140	22.5	AC	417
XUV 024020 ACG FS	2	135	15	360	240	20	AC	417
XUV 014020 ACG FS	2	160	12.5	260	140	22.5	AC	417
XUV 014020 ACG FS	2	260	7.7	260	140	22.5	AC	417
XUV 014030 ACG FS	3	220	14	260	140	25	AC	417
XUV 029035 ACG FS	3.5	220	22	420	290	15	AC	417
XUV 030036 ACG FS	3.6	220	22	420	300	20	AC	417
XUV 021040 BCG FS	4	450	9	280	210	23	BC	417
XUV 016050 ACG FS	5	380	13	285	160	28	AC	417
XUV 023060 BCG FS	6	500	12	350	230	26	BC	417
XUV 127100 BCG FS	10	1570	7	1425	1270	23	BC	417

If these parameters don't meet your requirements, please contact us. Our professional team will provide expert knowledge and custom drawings for your specific application.

Application Areas

UV ink, UV adhesive, UV painting, UV coating applications. Additional industries include paper glazing, printed circuit boards, decoration, wooden flooring, flexible packaging, color printing, electronics, glass manufacturing, furniture production, and related industrial processes.

After Sales Service

Package tracking
One year guarantee
Technical support
Discount for reorder
Replacements for quality problems
Confidentiality of customer information
