11x23mm Twin Tube Infrared Quartz Heater Lamp 200-6000W

11x23mm Twin Tube Infrared Quartz Heater Lamp 200-6000W

Brand Name:	UVIR
Model Number:	THC100151
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	L/C,D/P,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE & ROHS

Place Of Origin:

Guangdong, China

Power:

200-6000w

Voltage:

55-575V

Light Source:

Quartz Tube

Material:

Quartz

Head Base:

TC01

Coating:

Clear

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box

Highlight:

11x23mm twin tube infrared lamp

quartz heater lamp 200-6000W

twin tube quartz infrared heater

Product Description

11x23mm Halogen IR Infrared Tube Lamp Gold Coating Twin Tube Quartz Heater Lamp

Product Specifications

Attribute	Value
Place of Origin	Guangdong, China
Power	200-6000W
Voltage	55-575V
Light Source	Quartz Tube
Material	Quartz
Head Base	TC01
Coating	Clear

Product Overview

We specialize in manufacturing and wholesale distribution of ultraviolet lamps, infrared lamps, ultraviolet germicidal lamps, and related accessories including lamp stands and transformers. Custom solutions are available to meet specific customer requirements.

Key Advantages

High-quality quartz glass tube construction
Extended service life exceeding 5000 hours
Environmentally safe operation with no toxic emissions or odors
Zero risk of contamination to surrounding environment or heated objects

Standard Twin Tube Construction

Technical Parameters

Parameter	Specification
Product Name	Twin Tube Infrared Lamp
UVIR No.	THC100277
Voltage	55-575V
Power	200-6000W
Material	Quartz Glass
Color	Clear
Filament Temperature	1800-2400℃
Customization	Available for voltage, wattage, length, base type, cables, and universal burning position

Premium Materials

Our lamps combine high-quality transparent quartz tube materials with halogen principles to maximize infrared radiation density, achieving optimal heating performance for your specific applications.

Standard Product Specifications

Stock and Standard (Non-Stock) Twin Tube Short-Wave Lamps

Voltage (V)	Wattage (W)	Twin Tube	Total Length	Heated Length	Design Type	Gold	White	Clear
55	400	11x23	115	50	B	THG100151	THW100025	THC100026
115	400	11x23	115	50	B	THG100152	THW100026	THC100027
115	450	11x23	70	25	B	THG100153	THW100027	THC100028
115	450	11x23	72	25	B	THG100154	THW100028	THC100029
115	600	11x23	145	80	B	THG100155	THW100029	THC100030
115	900	11x23	170	115	B	THG100156	THW100030	THC100031
115	1000	11x23	192	127	B	THG100157	THW100031	THC100032
115	1100	11x23	205	140	B	THG100158	THW100032	THC100033
120	700	11x23	140	89	B	THG100159	THW100033	THC100034
120	800	11x23	167	102	B	THG100160	THW100034	THC100035
120	1180	11x23	250	150	B	THG100161	THW100035	THC100036
230	1200	11x23	405	340	B	THG100162	THW100036	THC100037
230	1500	11x23	300	200	B	THG100163	THW100037	THC100038
230	2350	11x23	410	355	B	THG100164	THW100038	THC100039
230	3000	11x23	650	500	C	THG100165	THW100039	THC100040
230	500	15x33	510	500	B	THG100114	THW100061	THC100061
400	4800	15x33	500	800	B	THG100141	THW100062	THC100062
400	6200	15x33	1100	1030	B	THG100002	THW100063	THC100063
400	15720	15x33	850	1334	H	THG100186	THW100064	THC100064
480	6000	15x33	1550	1000	B	THG100140	THW100065	THC100065

For custom specifications not listed above, please contact our technical team for professional consultation and custom drawings.

Product Coding System

Customer Support

Package tracking service
Comprehensive technical support
24-hour customer service
Discounts for repeat orders
Quality problem replacements
Strict customer information confidentiality

Industrial Applications

Heating Systems: Space heaters, saunas, electric hot tables, incubators, brooders, farm greenhouses
Automotive: Primer/color/powder coating, seat de-wrinkling, headliner forming
Plastics: Welding, forming, softening, curing, drying processes
Printing: Ink drying, silk screening, bindings, glue drying
Food Processing: Baking, browning, dehydrating, pasteurizing
Textiles: Web drying, finishing, pre-shrinking
Glass & Ceramics: Heating safety glass, drying mirrors, drying frit

Frequently Asked Questions

1. Are you a manufacturer?

Yes, we are a factory with over 15 years of experience in infrared lamp production. We welcome visits to our facility.

2. How can I obtain samples?

We provide free samples for quality evaluation, with customers responsible for shipping costs. Please contact our sales team to arrange samples.

3. What is the ordering process?

Contact our sales team via email or online chat to discuss your requirements. We will prepare a Proforma Invoice for your confirmation before processing your order upon payment.

4. Are your products safe?

All our products undergo rigorous testing and hold certifications including European CE and RoHS compliance, ensuring they meet international safety standards.

5. Do you offer custom designs?

We provide comprehensive OEM and ODM services. Our engineering team can help realize your specific design requirements.
