55V 400W Quartz Twin Tube Infrared Heater Lamp

55V 400W Quartz Twin Tube Infrared Heater Lamp

Brand Name:	UVIR
Model Number:	THC100151
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	L/C,D/P,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE & ROHS

Type:

Short Wave Halogen Infrared Heater

Material:

Quartz Glass

Warrant Time:

5000Hours

Shape:

Straight

Power:

400w

Place Of Origin:

Guangdong, China

Voltage:

55V

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box

Highlight:

Twin Tube Infrared Lamps 400w

Twin Tube Infrared Lamps 55V

400w Halogen Heater Element

Product Description

Clear Quartz Twin Tube Infrared Lamps, 55V 400W Halogen Heater Element

Product Specifications

Attribute	Value
Type	Short Wave Halogen Infrared Heater
Material	Quartz Glass
Warrant Time	5000 Hours
Shape	Straight
Power	400W
Place of Origin	Guangdong, China
Voltage	55V

Clear Quartz Twin Tube Halogen Heating Heater Infrared Lamp

Designed for rapid heating applications with superior infrared radiation efficiency.

Key Advantages

Energy efficient - provides up to 50% energy savings compared to conventional heating technologies
Exceptional and consistent product quality
24/7 customer support available
Certified with CE, ISO9001, RoHS, and SGS standards
Low minimum order quantity - samples available from 1 piece

Technical Parameters

Parameter	Value
Product Name	Twin Tube Infrared Lamp
UVIR No.	THC100151
Voltage	55V
Power	400W
Material	Quartz Glass
Color	Clear
Filament Temperature	1800-2400 ℃
OEM/ODM	Custom voltage, wattage, length, base, and cable configurations available

Premium Construction

Manufactured with high-quality transparent quartz tube materials combined with halogen technology to maximize infrared radiation density, achieving optimal heating performance.

Technical Specifications

The structural strength of our quartz tubes is enhanced by incorporating a steel beam design concept, allowing for twin tube lengths up to 6 meters (cross section: 33 X 14 mm).

Standard Cross-Section Dimensions

Cross-Section	Maximum Length (m)	S-W	M-W
8x18	2.1	N	Y
23x11	3.5	Y	Y
33x14	4.0	Y	Y

Note: Heater dimensions vary based on required voltage/wattage relationship.

Stock and Standard Twin Tube Short-Wave Lamps

Voltage (V)	Wattage (W)	Twin Tube	Total Length	Heated Length	Design Type	Gold	White	Clear
55	400	11x23	115	50	B	THG100151	THW100025	THC100026

Custom configurations available. Contact us for specialized requirements.

Quality Assurance

All infrared heater lamps meet CE & ROHS standards with strict quality control measures ensuring perfect performance.

Customization Services

Custom infrared heater lamps tailored to your specific requirements
Professional technical support for one-to-one service
Sample units available for quality testing
OEM services including custom branding

Warranty & Support

5,000-hour warranty for short wave infrared heat lamps
Free replacement for any non-manufacturing defects during warranty period

Frequently Asked Questions

What is the payment term?

100% prepayment via wire transfer, Paypal, or Western Union.

Could you provide sample for performance testing and appearance checking?

Yes, we can provide samples based on your required specifications.

What information should I provide when enquiring?

Please provide lamp type, dimensions, wattage, voltage, connection type, lead length, and any coating requirements. For new projects, include details about your application, target temperature, and heating requirements.
