5000h Lifetime Quartz Infrared Lamp with 1100-2600°C Filament Temperature and Customizable Base

5000h Lifetime Quartz Infrared Lamp with 1100-2600°C Filament Temperature and Customizable Base

Brand Name:	UVIR
Model Number:	SHG100500
MOQ:	2
Price:	Negotiable

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

Short Wave Single IR Lamp

Voltage:

55-575V

Wattage:

200-4000W

Material:

Tungsten(filament),quarz(tube)

Filament Temperature:

1100-2600°C

Lifetime:

5000h

Place Of Origin:

Guangdong, China

Base:

Customizable

Heating Length:

50-1500mm

Total Length:

50-1500mm

Tube Diameter:

8-24mm

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box.

Highlight:

5000h Lifetime Quartz Infrared Lamp

1100-2600°C Filament Temperature Halogen Tungsten Lamp

Customizable Base Infrared Heating Lamp

Product Description

Curing Preheating Dedicated Halogen Tungsten Lamp Single Tube Uncoated U-Shaped Molybdenum Rod Infrared Heating Light

Product Specifications

Attribute	Value
Product name	Short wave single IR Lamp
Voltage	55-575V
Wattage	200-4000W
Material	Tungsten (filament), quartz (tube)
Filament temperature	1100-2600°C
Lifetime	5000h
Place of Origin	Guangdong, China
Base	Customizable
Heating length	50-1500mm
Total length	50-1500mm
Tube diameter	8-24mm

Key Advantages

Premium Materials: Manufactured from imported high-end quartz tube
Extended Lifespan: 5000 hours operational life
High Efficiency: Over 85% heat efficiency at full power
Energy Saving: Gold reflective layer concentrates radiation energy
Clean Heating: No surface corrosion or contamination
Precise Control: Heating time can be precisely controlled
Environmentally Friendly: No contamination risk to environment or target objects
Customizable: Wavelength, dimensions, and filaments can be adjusted
Space Efficient: Compact design with superior heating performance

Standard Single Tube Construction

Additional standard end terminations available upon request.

Industrial Applications

Plastics Processing: IR drying of coatings, stretching/shrinking plastics, blow molding of PET bottles
Photovoltaic Industry: String soldering, preheating for sputtering processes
Printing Industry: Curing ink on cloth, drying for inkjet-based CTP plates
Food & Chemical Industry: Disinfection, food heating, herbal medicine processing
Glass Industry: Preheating car glass, drying coatings, manufacturing laminated glass
Textiles Industry: Drying coatings, laminating fabrics
Electronic Industry: Coatings on components, component aging processes

Our lamps are also suitable for use in flooring, metal, paper, packaging, powder, coating, rubber, wood, semiconductors, and other industries.

Manufacturing Capabilities

We specialize in production and wholesale of ultraviolet lamps, infrared lamps, germicidal lamps, xenon lamps, and related accessories. All products can be customized to meet specific requirements.

Frequently Asked Questions

Q1. Can all the products be customized?

A: We manufacture IR lamps, UV lamps, and accessories. All products can be made to your specifications.

Q2. What is the outer package of the product?

A: Standard packaging includes carton or wooden cases.

Q3. What is the processing cycle?

A: Some products are in stock. Custom orders typically require about 15 days.

Q4. What is the minimum order quantity?

A: Customized IR lamps typically have a minimum order of 10 pieces.

For specific requirements, please contact our sales team.
