Infrared Heating Halogen Tungsten Lamp with 5000h Lifetime U-shaped Molybdenum Rod and 1-2μm Wavelength for Industrial Curing

Infrared Heating Halogen Tungsten Lamp with 5000h Lifetime U-shaped Molybdenum Rod and 1-2μm Wavelength for Industrial Curing

Brand Name:	UVIR
Model Number:	-
MOQ:	10
Price:	Negotiable

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Name:

Short Wave Single IR Lamp

Voltage:

55-575V

Wattage:

200-4000W

Tube Diameters:

8-24mm

Material:

Tungsten(filament),quarz(tube)

Wavelength:

1-2μm

Lifetime:

5000h

Wave Length:

Short Wave

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box.

Highlight:

5000h Lifetime Infrared Heating Lamp

U-shaped Molybdenum Rod Halogen Tungsten Lamp

1-2μm Wavelength Quartz Infrared Lamp

Product Description

Infrared Heating Halogen Tungsten Lamp Single Tube Uncoated U-Shaped Molybdenum Rod for Industrial Curing Preheating

Product Specifications

Attribute	Value
Product name	Short wave single IR Lamp
Voltage	55-575V
Wattage	200-4000W
Tube diameters	8-24mm
Material	Tungsten (filament), Quartz (tube)
Wavelength	1-2μm
Lifetime	5000h
Wave Length	Medium wave

Product Highlights

U-shaped Molybdenum Rod Design: Made of high-purity molybdenum alloy material with excellent high-temperature resistance and oxidation resistance. The U-shaped structure ensures uniform heating and stable heat distribution, extending lamp tube lifespan.
Single-tube uncoated process: Uncoated quartz tube provides high infrared transmittance, low heat loss, and infrared radiation efficiency over 90%. Heats up quickly with significant energy-saving effects.
Halogen tungsten filament lamp core: High-purity halogen tungsten filament offers high luminous efficiency, low attenuation, and stable operating temperature, suitable for long-term continuous operation with reduced replacement frequency.
Infrared efficient heating: Short-wave/mid-wave infrared radiation directly penetrates surface layers, achieving rapid heating from inside out. 30%-50% more efficient than traditional hot air heating.
Dedicated to curing and preheating: Specifically designed for industrial curing and preheating scenarios, suitable for paint curing, powder coating baking, plastic preheating and molding, printing ink drying, and glass heat treatment.

Application Fields

Painting Industry: Automobile Paint Curing, Metal Surface Powder Coating Baking
Plastics Industry: Plastic Sheet Preheating and Forming, Blow Molding Heating, Heat Shrink Film Drying
Printing Industry: Ink Rapid Drying, UV Curing Preheating
Electronics Industry: PCB Board Preheating, Electronic Component Packaging Curing
Glass Industry: Glass Heat Treatment, Tempering Preheating
Textile Industry: Coating Drying, Heat Setting Treatment
Others: Food Packaging Heat Sealing, Laboratory Heating Equipment

Why Choose Us?

Source factory: Own production line with OEM/ODM customization support. Customize size, power, voltage, and spectrum parameters according to customer requirements.
Quality assurance: Imported high-purity molybdenum rods and tungsten filaments with quartz tube light transmittance ≥92%. Each lamp undergoes rigorous aging testing to ensure stable performance.
Quick delivery: Regular specifications available from stock, customized products delivered within 7-15 days with global logistics support.
Technical Support: Professional engineering team provides model selection guidance, installation advice, and after-sales technical support to optimize heating solutions.
Cost-effective advantage: Factory direct supply eliminates middlemen markups, offering better prices for equal quality and bulk purchase discounts.

Customized Services

Customization of lamp tube length, diameter, and U-shaped dimensions
Customization of power, voltage, and current
Customized shortwave/mid-wave/long-wave infrared spectroscopy
Customization of lamp base type (ceramic lamp base, metal lamp base, etc.)
Special coating or no coating option
Brand LOGO silk screen printing/packaging customization

Frequently Asked Questions

Q1: How long is the lifespan of this lamp tube?

A: Under rated voltage and normal usage conditions, the service life can reach 5000-8000 hours. Avoiding frequent switching and voltage fluctuations can further extend the lifespan.

Q2: Can samples be provided?

A: Yes, we support sample testing, and the sample fee can be deducted from the bulk order.

Q3: What is the minimum order quantity?

A: For regular specifications, a minimum order quantity of 1 piece is required. For customized products, the minimum order quantity is negotiable based on specific needs.

Q4: What is the shipping cycle?

A: Spot products will be shipped within 3-5 days, while customized products will be delivered within 15-20 days. The specific delivery time is subject to order confirmation.

Q5: How to choose the appropriate power and spectrum?

A: Please inform us of your application scenario, the material being heated, the heating area, and the temperature requirements. Our engineers will recommend the most suitable solution for you.
