Your Infrared Radiator Customization Expert
| Place of Origin: | China |
|---|---|
| Brand Name: | UVIR |
| Certification: | CE & ROHS |
| Model Number: | THC100151 |
| Minimum Order Quantity: | Negotiable |
| Price: | Negotiable |
| Packaging Details: | Each lamp in a cylinder .Then in a professional plywood box |
| Delivery Time: | 15-20Work day |
| Payment Terms: | L/C, D/P, T/T, Western Union |
| Place Of Origin: | Guangdong, China | Power: | 400w |
|---|---|---|---|
| Voltage: | 55V | Light Source: | Quartz Tube |
| Material: | Quartz | Head Base: | TC01 |
| Coating: | Clear | ||
| High Light: | TC01 Quartz Tube Infrared Heaters,Quartz Tube Infrared Heaters 55V,400w halogen heater replacement tubes |
||
Our company produces and wholesales: ultraviolet lamps, infrared lamps, ultraviolet germicidal lamps and other special light sources and peripheral accessories products, lamp stands, transformers, etc. Various products can be customized according to customer requirements.
The Advantages Of UVIR Heat Lamp
Guartz glass tube
1.High quality high-temperature quartz glass.
2.Long serving life: over 5000 hours.
3.nontoxic and peculiar smell, no risk of contamination over environment or target object to be heated.
Standard twin tube construction types
Product parameters
| Product name | Twin tueb infrared lamp |
| UVIR NO. | THC100151 |
| Voltage | 55V |
| Power | 400W |
| Material | Quartz Glass |
| Color | Clear |
|
Filament Temperature |
1800-2400 ℃ |
| OEM/ODM | many types of voltage,wattage,length,base,cables,universal burning position is available |
High quality raw material:
Combining high-quality transparent quartz tube materials and halogen principles,effectively increasing the density of infrared radiation. This achieves the user's ideal heating purpose.
Stock and Standard (Non-Stock) Twin Tu be Short-Wave Lamps
| Voltage V |
Wattage W |
Twin Tube |
Total Length |
Heated Length |
Disgn Type |
Gold | White | Clear |
| 55 | 400 | 11x23 | 115 | 50 | B | THG100151 | THW100025 | THC100026 |
| 115 | 400 | 11x23 | 115 | 50 | B | THG100152 | THW100026 | THC100027 |
| 115 | 450 | 11x23 | 70 | 25 | B | THG100153 | THW100027 | THC100028 |
| 115 | 450 | 11x23 | 72 | 25 | B | THG100154 | THW100028 | THC100029 |
| 115 | 600 | 11x23 | 145 | 80 | B | THG100155 | THW100029 | THC100030 |
| 115 | 900 | 11x23 | 170 | 115 | B | THG100156 | THW100030 | THC100031 |
| 115 | 1000 | 11x23 | 192 | 127 | B | THG100157 | THW100031 | THC100032 |
| 115 | 1100 | 11x23 | 205 | 140 | B | THG100158 | THW100032 | THC100033 |
| 120 | 700 | 11x23 | 140 | 89 | B | THG100159 | THW100033 | THC100034 |
| 120 | 800 | 11x23 | 167 | 102 | B | THG100160 | THW100034 | THC100035 |
| 120 | 1180 | 11x23 | 250 | 150 | B | THG100161 | THW100035 | THC100036 |
| 230 | 1200 | 11x23 | 405 | 340 | B | THG100162 | THW100036 | THC100037 |
| 230 | 1500 | 11x23 | 300 | 200 | B | THG100163 | THW100037 | THC100038 |
| 230 | 2350 | 11x23 | 410 | 355 | B | THG100164 | THW100038 | THC100039 |
| 230 | 3000 | 11x23 | 650 | 500 | C | THG100165 | THW100039 | THC100040 |
| 230 | 500 | 15x33 | 510 | 500 | B | THG100114 | THW100061 | THC100061 |
| 400 | 4800 | 15x33 | 500 | 800 | B | THG100141 | THW100062 | THC100062 |
| 400 | 6200 | 15x33 | 1100 | 1030 | B | THG100002 | THW100063 | THC100063 |
| 400 | 15720 | 15x33 | 850 | 1334 | H | THG100186 | THW100064 | THC100064 |
| 480 | 6000 | 15x33 | 1550 | 1000 | B | THG100140 | THW100065 | THC100065 |
If the parameter is not suitable for you,Please contact me.We have a professional elite team,will provide the professional knowledge and drawings for you!
Product Coding Rule Table
After Sales Service
1. Package tracking
2. Technical support
3. 24 hours working time
4. Discount for reorder
5. Replacements for quality problems
6. Confidentiality of customer information
Scope of application
Heater: Space heater, Sauna, Electric hot table, Incubating, Brooders, Farm green house.
- Automotive: Primer/Color/Powder coat, Seat de-wrinkling, Head liner forming
- Plastics: Welding, Forming, Softening, Curing, Drying
- Printing: Ink drying, Silk Screening, Bindings, Glue drying
- Food: Baking, Browning, Dehydrating, Pasteurizing
- Textiles: Web Drying, Finishing, Pre-shrinking
- Glass-Ceramics: Heating safety glass, Drying mirrors, Drying frit.
