55-575V Tungsten Filament Quartz Infrared Lamp with 1-2μm Wavelength and 5000h Working Time

55-575V Tungsten Filament Quartz Infrared Lamp with 1-2μm Wavelength and 5000h Working Time

Brand Name:	UVIR
Model Number:	-
MOQ:	10
Price:	Negotiable

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Reflector:

Clear

Voltage:

55-575V

Warranty(Year):

1-Year

Tube Diameters:

8-24mm,Customized

Material:

Tungsten

Wavelength:

1-2μm

Working Time:

5000h

Heating Length:

50-1500mm,Customized

Start Time:

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box.

Highlight:

55-575V Quartz Infrared Lamp

1-2μm Wavelength Infrared Heating Emitter

5000h Working Time Tungsten Filament Heater

Product Description

55-575V Tungsten Filament Quartz Heater Lamp Infrared Heating Emitters

High-performance infrared heating emitters featuring tungsten filament technology for efficient, direct energy transfer across industrial applications.

Product Specifications

Attribute	Value
Reflector	Clear
Voltage	55-575V
Warranty	1-Year
Tube diameters	8-24mm, Customized
Material	Tungsten
Wavelength	1-2μm
Working Time	5000h
Heating length	50-1500mm, Customized
Start Time	1s

Infrared Heating Advantages

Infrared radiators outperform traditional heating methods with direct energy transfer, precise temperature control, and up to 50% energy savings compared to conventional heating systems.

Technical Details

High-quality transparent quartz tube construction
Power range: 200-5,000W
Voltage options: 24-575V
Available in short, medium, and long-wave IR designs
Filament temperatures: 1,100°C to 2,600°C
Fast response time (1 second for short-wave)
Standard and custom configurations available

The infrared heating lamp ceramic base is constructed from high-quality, heat-resistant ceramic material for superior durability.

Standard Construction Types

Industrial Applications

Plastics Processing: IR drying, stretching, shrinking, and blow molding
Photovoltaic Industry: String soldering and sputtering preheating
Printing Industry: Ink curing and drying applications
Food & Chemical: Disinfection, food heating, and snow removal
Glass Industry: Preheating, coating drying, and laminated glass production
Textiles: Coating drying and fabric laminating
Electronics: Component coating and aging processes

Our infrared heating solutions are also suitable for flooring, metal, paper, packaging, rubber, wood, semiconductors, and other industrial applications.

Our Commitment to Quality

Dedicated sales team for accurate communication
Professional technical team for product development
Experienced production team for quality manufacturing
Rigorous quality inspection process
Comprehensive after-sales support
