UVC Germicidal Lamp
Created with Pixso.

GPH436T5L HO 4PIN UV Germicidal Lamp 436mm 48W for Hospital

GPH436T5L HO 4PIN UV Germicidal Lamp 436mm 48W for Hospital

Brand Name: UVIR
Model Number: GPH436T5L/HO
MOQ: 100
Price: Negotiable
Payment Terms: L/C,T/T,Western Union
Detail Information
Place of Origin:
China
Certification:
CE
Keyword:
Germicidal Lamps
Type:
4PIN UV Light
Lenght:
436mm
Lifespan (hours):
10000-13000h
Application:
Home, Medical, Hotel, Office, Air Purification And Water Treatment
Color Of End:
White
Warranty(Year):
1-Year
Lamp Tube Material:
High Quality Quartz
Packaging Details:
Each lamp in a cylinder .Then in a professional plywood box.
Highlight:

Uv Germicidal Lamp Uvc With Ozone

,

Hospital GPH436T5L HO

,

GPH436T5L HO

Product Description
GPH436T5L HO Uv Germicidal Lamp UVC With Ozone for Hospital
Product Attributes
Attribute Value
Keyword Germicidal lamps
Type 4PIN UV Light
Length 436mm
Lifespan (hours) 10000-13000h
Application Home, Medical, Hotel, Office, Air purification and water treatment
Color of end White
Warranty 1-Year
Lamp tube material High quality quartz
Product Description

GPH436T5L/HO UV ozone germicidal sterilizer medical mercury UV lamp light ultraviolet for hospital.

Ultraviolet Light

The UVC lamp is made by quartz tube which can penetrate the ultraviolet wavelength 254nm. Ultraviolet wave 185nm produces ozone which be dissolved in water to destroy the walls of the cells of microorganism, and thereby kill them immediately.

Specification Details
  • Main body material: High quality Quartz glass
  • Ends material: Ceramic, aluminum, plastic
  • Color: Main body tubes are clear, the ends color can be made according to customers' request
  • Tube Voltage: can make according to customized request
  • Wattage: can make according to customized request
  • Type: Single end or Double-end
  • Average Lifetime: 10000h - 13000h
GPH436T5L HO 4PIN UV Germicidal Lamp 436mm 48W for Hospital 0
Product Information
Product name 4 PIN Double End For UV germicidal lamp
Model NO. GPH436T5L/HO
Overall Length 436mm
Watt 48W
Diameter 15mm
Ultraviolet intensity at 1 meter 120uw/cm2
Current 800mA
Lifetime 10000-13000hrs

The wave penetration rate of the ultraviolet light is higher and the intensity is greater; Quartz material, longer life.

GPH436T5L HO 4PIN UV Germicidal Lamp 436mm 48W for Hospital 1
HIGH OUTPUT

HO is the High output type. By increasing the filament, Change the inflation, and increasing the current, etc., the power of the lamp can be increased without lengthening the lamp.

GPH436T5L HO 4PIN UV Germicidal Lamp 436mm 48W for Hospital 2
Application
  • Water treatment for sanitary wastewater or industry sewage pools etc.
  • Sterilizing and Algae remover for aquarium, farming ponds, landscape water area etc.
GPH436T5L HO 4PIN UV Germicidal Lamp 436mm 48W for Hospital 3 GPH436T5L HO 4PIN UV Germicidal Lamp 436mm 48W for Hospital 4
Matters Need Attention When Using a UV Lamp

The radiation of those UV lamps is harmful to eyes and skin. Protect your eyes and your skin against the ultraviolet rays.

  • Don't look at the UV lamp directly when the UV lamp is igniting. Hold a piece of ordinary glass before your eyes when you need to look at the UV-lamp.
  • Don't irradiate the skin under UV-lamp.
  • Please keep the surface of the tube clean to prevent the dust or the dirt from affecting the ultraviolet ray's output.
  • Please don't touch the quartz glass with bare hands while installing the lamp and using it.
  • The quartz glass can be cleaned by using alcohol tampon if there is dirty stains on the lamp.
