8W G5 UVC Germicidal Lamp for Air Conditioning and Purification

Name: 8W G5 UVC Germicidal Lamp for Air Conditioning and Purification
Brand: Guangdong Youhui Technology Co., Ltd.
SKU: G8T5
Price: 3.00 USD
Availability: InStock

Brand Name:	UVIR
Model Number:	G8T5
MOQ:	10
Price:	Negotiable
Payment Terms:	L/C,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

End Material:

Ceramic / Aluminum

Lamp Tube Material:

High Quality Quartz

Type:

Single End 2-pin

Power:

Voltage High Frequency:

Overall Length:

288

Base Type:

Application:

Home, Medical, Hotel, Office, Air Purification And Water Treatment

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box.

Highlight:

8W UVC Germicidal Lamp

Air Conditioning UVC Germicidal Lamp

G8t5 Uv Light Bulb

Product Description

8W UVC Germicidal Lamp, Air Conditioning G8t5 Uv Light Bulb

Product Specifications

Attribute	Value
End material	Ceramic / aluminum
Lamp tube material	High quality quartz
Type	Single end 2-pin
Power	8W
Voltage high frequency	45
Overall length	288
Base Type	G5
Application	Home, Medical, Hotel, Office, Air purification and water treatment

Product Description

G8T5 8W Quartz Ultraviolet Sterilize Germicidal UV Lamps Tube Double-End 2 Pins Air Conditioning Ultraviolet Germicidal light

Why Choose Our UV Lamps

Lamps are approved by CE and RoHS
Implement strict quality system according to ISO9001
All lamps are tested individually before delivery
1 year warranty with free replacements or repairs
Fast delivery: samples within 5 working days, bulk orders within 25 days
Dependable after-sales service
ODM and OEM service available
Low MOQ requirements
24/7 customer support with responses within 24 hours

About UV Germicidal Technology

Ultraviolet sterilization lamps are available in two types: without ozone and with ozone. No-ozone UV germicidal lamps disinfect only where the ultraviolet light directly reaches, while ozone UV lamps provide ultraviolet + ozone double sterilization that can reach blocked areas and eliminate dead zones.

Technical Details

Feature	Specification
Product name	2 PIN Double End For UV germicidal lamp
Power options	4w/6w/8w/11w/16w
Voltage	110v/220v
Lamp base	G5
Pipe diameter	15mm (T5) / 25mm(T8)
Scope of application	Home/hospital/school/industrial use
Main material	High boron/Quartz germicidal glass/aluminum head/copper needle
Lamp length	135mm/212mm/288mm

The quartz material provides higher UV wave penetration rate and greater intensity, along with longer lifespan.

Specification Details

Main body material: High quality Quartz glass
Ends material: Ceramic, aluminum, plastic
Color: Clear tubes with customizable end colors
Customizable tube voltage and wattage
Available in single end or double-end configurations
Average Lifetime: 10,000h - 13,000h

Available Models

Model No	Base	Length (mm)	Watt	Diameter (mm)	Voltage50/60Hz	Voltage HF	Current (MA)	UV Intensity (uw/cm²)
Tube Diameter: T5=15mm
G4T5	G5	135	4	15	28	23	170	9
G6T5	G5	212	6	15	42	34	160	16
G8T5	G5	288	8	15	56	45	150	21
G11T5	G5	212	11	15	49	40	330	22
G16T5	G5	288	16	15	54	44	350	36
Tube Diameter: T8=25mm
G10T8	G13	331	10	25	46	36	230	23
G15T8	G13	437	15	25	51	44	340	47
G20T8	G13	589	20	25	60	50	360	65
G25T8	G13	437	25	25	43	41	600	70
G30T8	G13	894	30	25	100	80	370	100
G36T8	G13	1199	36	25	103	87	440	145
G55T8	G13	894	55	25	87	70	780	160
G75T8	G13	1199	75	25	110	85	850	220

We supply a complete series of UVC lamps including two end 2-pin, one end 4-pin, and PL UVC lamps. Custom solutions are available - please contact us with your requirements.

Applications

Ultraviolet germicidal lamps are widely used in homes, hospitals, schools, nurseries, movie theaters, buses, offices, and other spaces. They effectively purify air, eliminate moldy odors, and generate negative oxygen ions for fresher environments. In public spaces, UV disinfection prevents germ transmission through air or surface contact.

Frequently Asked Questions

Q1: Are you factory or trading company?

A: We are trading company with factory.

Q2: Can I have a sample first before bulk order?

A: Yes. We offer free samples for quality testing, you only pay the freight.

Q3: What's your delivery date?

A: 5-7 working days for samples and 15-25 days for bulk orders.

Q4: What's your shipping methods?

A: 1. By Express: TNT, DHL, FedEX, UPS, EMS (door to door)
2. By Air: To your specified airport
3. By Sea: To your delivery port

Q5: What's your MOQ?

A: Our standard MOQ is 100pcs, but sample orders can be smaller.

Q6: Are the products safe enough?

A: Our products undergo thorough testing and are certified by internationally recognized regulatory bodies and safety organizations.
