39-606mm Ring Infrared Quartz Heater Lamp for Plastic Welding

39-606mm Ring Infrared Quartz Heater Lamp for Plastic Welding

Brand Name:	UVIR
Model Number:	-
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE & ROHS

Power:

200-6000W

Tube Diameter:

8-14mm

Type:

Quartz Pipe With White Coating

Application:

Heating

Shape:

Ring Or Round

Customized:

Yes

Head Base:

Ceramic

Place Of Origin:

Guangdong, China

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box

Highlight:

UVIR Infrared Quartz Heater Lamp

Product Description

39-606mm UVIR Ring Tube Infrared Quartz Heater Lamp for Plastic Welding

Product Specifications

Attribute	Value
Power	200-6000W
Tube diameter	8-14mm
Type	Quartz Pipe With White Coating
Application	Heating
Shape	Ring or Round
Customized	Yes
Head Base	Ceramic
Place of Origin	Guangdong, China

Product Advantages

Carbon Fiber Heat Lamp

High-quality imported carbon fiber filament
Smooth finished filament that doesn't fluff
Optimized power efficiency and maximum longevity

Quartz Glass Tube

Premium high-temperature quartz glass construction
Extended service life: over 5000 hours
Non-toxic and odorless, with no risk of environmental contamination

Main Design Characteristics

Ring diameter from 39mm to 600mm
Voltage range from 24V to 575V
Available in short, medium, and long-wave IR designs
Multiple tube color options available
Tube diameter options from 8mm to 14mm
Standard stock items for immediate delivery
Custom and OEM designs available

Detailed Specifications

Product Name	Ring tube infrared lamp
Tube Diameter	8-14mm
Voltage	55-575V
Wattage	200-6000W
Coating	White

Quick Connect Ring 39mm

Stock and Standard (Non-Stock) Ring Short-Wave Ø39mm Quick Connect Lamps

#	Voltage (V)	Wattage (W)	Diameter (mm)	Model 1	Model 2	Model 3	Model 4
1	115	200	8	RHC800300	RHG800300	RHG800306	RHG800312
2	115	200	10	RHC800301	RHG800301	RHG800307	RHG800313
3	115	450	8	RHC800302	RHG800302	RHG800308	RHG800314
4	220	200	8	RHC800303	RHG800303	RHG800309	RHG800315
5	220	300	8	RHC800304	RHG800304	RHG800310	RHG800316
6	220	450	8	RHC800305	RHG800305	RHG800311	RHG800317

OEM Services

We provide expert guidance in selecting the optimal heat lamp for specific applications. Our technical team can design custom solutions based on your precise technical requirements.

We manufacture various sizes and types of heat lamps according to customer specifications. Providing drawings is ideal for accurate sample production.

Industry Applications

Automotive: Primer/color/powder coating, seat de-wrinkling, headliner forming
Plastics: Welding, forming, softening, curing, drying
Printing: Ink drying, silk screening, bindings, glue drying
Food: Baking, browning, dehydrating, pasteurizing
Textiles: Web drying, finishing, pre-shrinking
Glass-Ceramics: Heating safety glass, drying mirrors, drying frit

Frequently Asked Questions

1. How does your factory handle quality control?

"Quality is priority" - UVIR maintains strict quality control from start to finish. Our factory is certified with CE, ISO9001, RoHS, and SGS standards.

2. Do you offer customized services?

We provide tailored heating solutions and OEM services, including custom branding as per your requirements.

3. What is your after-sales service policy?

We guarantee compensation for any confirmed quality issues.

4. What are your shipping terms?

Orders typically ship within 3 days to confirmed addresses only. Transit times are carrier estimates excluding weekends/holidays.

5. Can I request samples? Are they free?

Yes, we provide samples for evaluation. Sample costs depend on quantity and product model.
