32W T5 UVC Germicidal Lamp 254nm Quartz Tube

32W T5 UVC Germicidal Lamp 254nm Quartz Tube

Brand Name:	UVIR
Model Number:	GPH357T5L/HO
MOQ:	100
Price:	Negotiable
Payment Terms:	L/C,T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Lamp Tube Material:

High Quality Quartz

Type:

Amalgam Lamp With Single Ended 4 Pins

Lenght:

357mm

Lifespan (hours):

10000-13000h

End Material:

Ceramic

Warranty(Year):

1-Year

Keyword:

Germicidal Lamps

Application:

Home, Medical, Hotel, Office, Air Purification And Water Treatment

Packaging Details:

Each lamp in a cylinder .Then in a professional plywood box.

Highlight:

254nm UVC Germicidal Lamp

32W UVC Tube Light

T5 UVC Tube Light

Product Description

32W T5 UVC Germicidal Lamp - 254nm Wavelength

Product Attributes

Lamp tube material	High quality quartz
Type	Amalgam lamp with single ended 4 pins
Length	357mm
Lifespan (hours)	10000-13000h
End material	Ceramic
Warranty	1-Year
Applications	Home, Medical, Hotel, Office, Air purification and water treatment

Product Description

This UV germicidal sterilizer tube light features a high-quality quartz glass construction that effectively emits UVC light at 254nm wavelength for superior disinfection performance.

Ultraviolet Light Technology

The UVC lamp utilizes a quartz tube that penetrates ultraviolet wavelength at 254nm. The 185nm ultraviolet wave produces ozone which dissolves in water to destroy microorganism cell walls, providing immediate sterilization.

Specification Details

Main body material: High quality Quartz glass
Ends material: Ceramic, aluminum, plastic
Color: Clear tubes with customizable end colors
Customizable voltage and wattage available
Type: Single end or Double-end options
Average Lifetime: 10000h - 13000h

Technical Specifications

Product name	4 PIN Double End For UV germicidal lamp
Model NO.	GPH357T5L/HO
Overall Length	357mm
Wattage	32W
Diameter	15mm
Ultraviolet intensity at 1 meter	95uw/cm2
Current	800mA
Lifetime	10000-13000hrs

The wave penetration rate of the ultraviolet light is higher and the intensity is greater; Quartz material ensures longer life.

HIGH OUTPUT Technology

HO (High Output) type increases lamp power without lengthening the lamp through enhanced filament design, modified inflation, and increased current.

Product Series Specifications

Tube Diameter: T5=15mm

Model	Pins	Length (mm)	Wattage	Diameter (mm)	UV Intensity (μW/cm²)	Current (mA)
GPH212T5L/HO	4pin	212	18	15	50	800
GPH287T5L/HO	4pin	287	27	15	75	800
GPH357T5L/HO	4pin	357	32	15	95	800
GPH436T5L/HO	4pin	436	48	15	120	800
GPH793T5L/HO	4pin	793	72	15	210	800
GPH846T5L/HO	4pin	846	80	15	260	800
GPH893T5L/HO	4pin	893	90	15	270	800
GPH1148T5L/HO	4pin	1148	120	15	310	800
GPH1554T5L/HO	4pin	1554	145	15	400	800

Applications

Water treatment for sanitary wastewater or industry sewage pools
Sterilizing and algae removal for aquariums, farming ponds, and landscape water areas

Frequently Asked Questions

Q1. Can I have a sample order?

A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A: Samples need 5-7 days, about 30 days for mass production.

Q3. Do you have any MOQ limit?

A: Usually MOQ is 100pcs for each model.

Q4. How do you ship the goods?

A: We usually ship by DHL, UPS, FedEx or TNT for samples. Airline and sea shipping for large quantities.

Q5. How to proceed an order?

A: First let us know your requirements. Second we quote according to your needs. Third customer confirms samples and places deposit. Fourth we arrange production.

Q6: How to deal with the faulty?

A: Our products have strict quality control. During guarantee period, we send replacements with next order.
